NOTES:

Part #	Number on image	Usage Notes
411-322-050	42	C/W Nyloc Nut

718 - Stealth Original FM 340 - Drive System

Stealth Original FM 340

Grouped product items
No.	Product Name	Price
1	PTO Complete Driveshaft - 540/1000rpm - Trimax Specification 406-340-870 More Info >	US$428.53
2	Bolt - Hex Head - M8 x 16 - Trimax Specification 301-208-163 More Info >	US$1.05
3	Washer - Flat 308-080-016 More Info >	US$0.25
4	Cone 410-440-400 More Info >	US$25.22
5	Gearbox - Standard Rotation - 540rpm 405-200-720 More Info >	US$1,405.69
7	Gearbox - Breather 405-207-207 More Info >	US$21.66
8	Blanking Plug - M12 209-900-012 More Info >	US$0.35
9	Key - Gearbox 405-207-154 More Info >	US$10.29
10	Bolt - Hex Head - M12 x 30 - Trimax Specification 301-212-303 More Info >	US$3.13
11	Washer - Spring M12 - Trimax Specification - 308-120-043 More Info >	US$0.60
12	Pulley - Taper Lock 403-361-270 More Info >	US$240.93
13	Bush - Taper Lock 402-060-680 More Info >	US$87.26
14	Bolt - Hex Head - M8 x 20 - Trimax Specification 301-208-203 More Info >	US$1.05
15	Retainer Ring 402-060-450 More Info >	US$10.81
16	Bush 402-060-320 More Info >	US$27.23
17	Pulley 403-360-300 More Info >	US$63.88
18	Bolt - Hex Head - M8 x 40 - Trimax Specification 301-208-403 More Info >	US$1.64
19	Vee Belt - Trimax Specification 404-040-830 More Info >	US$51.54
20	Vee Belt - Trimax Specification 404-041-300 More Info >	US$84.34
21	Nut - Half 307-212-023 More Info >	US$0.80
23	Pulley Assembly - Idler 403-360-111 More Info >	US$70.88
24	Washer - Flat 108-071-413 More Info >	US$2.53
25	Stud 403-330-443 More Info >	US$2.27
26	Nut - Plain M12 - Trimax Specification - 307-212-013 More Info >	US$0.60
27	Washer - Flat M12 - Trimax Specification - 308-120-013 More Info >	US$0.45
28	Washer - Heavy Flat 308-120-063 More Info >	US$0.89
29	Bolt - Hex Head - M12 x 45 - Trimax Specification 301-212-453 More Info >	US$3.72
30	Idler Tower Incl Base 403-330-442 More Info >	US$63.96
31	Idler Tower Incl Base 403-330-432 More Info >	US$62.73
32	Idler Tower Incl Base 403-330-423 More Info >	US$62.65
33	Idler Tower Incl Base 403-330-424 More Info >	US$60.30
34	Spindle Assembly - Type 5a Ext 50mm 504-328-042 More Info >	US$784.85
35	Spindle Assembly - Type 5b Short Ext 50mm 504-328-043 More Info >	US$715.98
36	Nut - Flange 450-000-078 More Info >	US$0.44
37	Bolt - Hex Head - M12 x 50 - Trimax Specification 301-212-503 More Info >	US$3.87
38	Washer - Hardened 108-071-513 More Info >	US$2.98
40	Blade Beam - LazerBladez 411-322-762 More Info >	US$69.40
41	Blade - LazerBlade Uplift - Uplift Profile Rotary Cutting Blade 411-160-842 More Info >	US$6.91
42	Blade Bolt - With M12 Nyloc Nut - LazerBlade and NexaBlade Mounting i See notes section for usage notes on this part 411-322-050 More Info >	US$4.28
43	Nut - Nyloc M12 - Trimax Specification - 307-212-053 More Info >	US$0.74
44	Clamp Plate - LazerBladez 411-322-820 More Info >	US$21.40
