NOTES:

Part # Number on image Usage Notes
301-212-303 3
  • All gearbox mounting hardware changed from M16 to M12 with the gearbox change. Supply serial number when ordering.
417-480-331 23
  • Rotor mounting bolts are now M16, replacing M12 bolts and sleeves. M12 bolts and rotor half rings are still available on request.
301-216-453 24
  • Rotor mounting bolts are now M16, replacing M12 bolts and sleeves. M12 bolts and rotor half rings are still available on request.
404-040-512 35
  • For serial numbers WLD276 onwards, use [404-040-512] Vee Belt. For serial numbers WLD275 and earlier, use [404-040-561] Vee Belt.
402-060-710 40
  • Used on all 4 belt machines (235, 265 and 295).
403-361-270 42
  • For serial numbers WLD276 onwards, use [403-361-270] G/Box Pulley - 200mm 4 Belt. For serial numbers WLD275 and earlier, use [403-361-280] G/Box Pulley - 250mm 4 Belt.
405-200-720 44
  • For serial numbers WLD276 onwards, use [405-200-720] Gearbox - TV 311 H. For serial numbers WLD275 and earlier, use [405-201-781] Gearbox - TL 278 E (145 and 175 sizes) or [405-201-901] Gearbox - TL 278 E (205 to 295 sizes). All gearbox mounting hardware changed from M16 to M12 with the gearbox change - supply serial number when ordering.
405-201-770 45
  • Always supply serial number, as gearbox extension lengths can vary. Fitted from serial number WLD275 onwards.
405-201-780 45
  • Always supply serial number, as gearbox extension lengths can vary. Fitted from serial number WLD275 onwards.
405-201-900 45
  • Always supply serial number, as gearbox extension lengths can vary. Fitted from serial number WLD275 onwards.
405-201-920 45
  • Always supply serial number, as gearbox extension lengths can vary. Fitted from serial number WLD275 onwards.
410-480-443 36
  • For left hand offset machines only.
405-200-721 44
  • For left hand offset machines only.

WL - Warlord S1 295 - Complete Assembly

Warlord S1 295

Grouped product items
No. Image Product Name Price Quantity
3 Bolt - Hex Head - M12 x 30 - Trimax Specification [301-212-303] Bolt - Hex Head - M12 x 30 - Trimax Specification i See notes section for usage notes on this part 301-212-303
US$3.13
4 Washer - Spring M12 - Trimax Specification - [308-120-043] Washer - Spring M12 - Trimax Specification - 308-120-043
US$0.60
5 Nut - Plain M12 - Trimax Specification - [307-212-013] Nut - Plain M12 - Trimax Specification - 307-212-013
US$0.60
6 Front Flap Weldment [417-480-320] Front Flap Weldment 417-480-320
US$30.75
8 Trailing Arm Weldment - SR LH WL [412-480-351] Trailing Arm Weldment - SR LH WL 412-480-351
US$106.21
9 Trailing Arm Weldment - SR RH WL [412-480-352] Trailing Arm Weldment - SR RH WL 412-480-352
US$106.21
10 Bolt - Hex Head - M16 x 40 - Trimax Specification [301-216-403] Bolt - Hex Head - M16 x 40 - Trimax Specification 301-216-403
US$1.43
11 Washer - Spring [308-160-043] Washer - Spring 308-160-043
US$0.60
12 Washer - Heavy Flat [308-160-063] Washer - Heavy Flat 308-160-063
US$0.74
14 Sleeve [402-464-062] Sleeve 402-464-062
US$7.13
15 Bolt - Hex Head - M12 x 50 - Trimax Specification [301-212-503] Bolt - Hex Head - M12 x 50 - Trimax Specification 301-212-503
US$3.87
16 Shield [410-464-052] Shield 410-464-052
US$14.40
17 Bearing Housing [401-020-800] Bearing Housing 401-020-800
US$21.36
18 Sleeve [402-480-740] Sleeve 402-480-740
US$1.72
20 Cap [410-464-072] Cap 410-464-072
US$24.48
21 Grease Nipple - Trimax Specification [208-442-620] Grease Nipple - Trimax Specification 208-442-620
US$4.02
22 Bearing Guard [410-460-302] Bearing Guard 410-460-302
Price on Request
23 Half Ring Lower Weldment - Rotor (M16 Captive Nuts) [417-480-331] Half Ring Lower Weldment - Rotor (M16 Captive Nuts) i See notes section for usage notes on this part 417-480-331
US$40.10
24 Bolt - Hex Head - M16 x 45 - Trimax Specification [301-216-453] Bolt - Hex Head - M16 x 45 - Trimax Specification i See notes section for usage notes on this part 301-216-453
US$6.85
25 Sleeve - Taper [401-021-230] Sleeve - Taper 401-021-230
US$42.29
26 Bearing [401-021-210] Bearing 401-021-210
US$63.26
27 Bearing Housing [401-021-220] Bearing Housing 401-021-220
US$71.94
29 Flail Lug [411-480-610] Flail Lug 411-480-610
US$19.07
30 Bolt - Hex Head M16 x 60 with Hex Nyloc Nut M16 - Trimax Specification [306-216-805] Bolt - Hex Head M16 x 60 with Hex Nyloc Nut M16 - Trimax Specification 306-216-805
US$12.21
31 Flail - Spring Steel Flail - Warlord - Trimax Specification - [411-160-200] Flail - Spring Steel Flail - Warlord - Trimax Specification - 411-160-200
US$32.80
32 Key - Trimax Specification [205-425-920] Key - Trimax Specification 205-425-920
US$12.21
33 Bush - Taper Lock - Trimax Specification [402-060-730] Bush - Taper Lock - Trimax Specification 402-060-730
US$64.08
34 Pulley - Taper Lock [403-361-180] Pulley - Taper Lock 403-361-180
US$143.26
35 Vee Belt - Trimax Specification [404-040-512] Vee Belt - Trimax Specification i See notes section for usage notes on this part 404-040-512
US$77.96
36 Belt Guard Weldment - RH Offset [410-480-440] Belt Guard Weldment - RH Offset 410-480-440
US$612.44
38 Drop Latch - Anti-loose [423-080-400] Drop Latch - Anti-loose 423-080-400
US$25.10
39 Nut - Nyloc M12 - Trimax Specification - [307-212-053] Nut - Nyloc M12 - Trimax Specification - 307-212-053
US$0.74
40 Bush - Taper Lock - Trimax Specification [402-060-710] Bush - Taper Lock - Trimax Specification i See notes section for usage notes on this part 402-060-710
US$81.18
41 Key - 12x8mm - Trimax Specification [405-425-910] Key - 12x8mm - Trimax Specification 405-425-910
US$11.39
42 Pulley - Taper Lock [403-361-270] Pulley - Taper Lock i See notes section for usage notes on this part 403-361-270
US$240.93
44 Gearbox - Standard Rotation - 540rpm [405-200-720] Gearbox - Standard Rotation - 540rpm i See notes section for usage notes on this part 405-200-720
US$1,405.69
45 Extension Assembly [405-201-770] Extension Assembly i See notes section for usage notes on this part 405-201-770
US$796.35
45 Extension Shaft Assembly - Gearbox [405-201-780] Extension Shaft Assembly - Gearbox i See notes section for usage notes on this part 405-201-780
US$622.41
45 Extension Assembly [405-201-900] Extension Assembly i See notes section for usage notes on this part 405-201-900
US$985.12
45 Extension Assembly [405-201-920] Extension Assembly i See notes section for usage notes on this part 405-201-920
Price on Request
47 Nut - Plain [307-216-013] Nut - Plain 307-216-013
US$1.05
48 Bolt - Hex Head - M16 x 35 - Trimax Specification [301-216-353] Bolt - Hex Head - M16 x 35 - Trimax Specification 301-216-353
US$6.85
49 U-Bolt [215-446-320] U-Bolt 215-446-320
US$24.56
51 Pin - Linkage - Top Link [419-301-150] Pin - Linkage - Top Link 419-301-150
US$13.68
52 Washer - Heavy Flat M20 - Trimax Specification - [308-200-064] Washer - Heavy Flat M20 - Trimax Specification - 308-200-064
US$1.05
53 Pin - Linkage - Lower Dual Cat. [419-300-900] Pin - Linkage - Lower Dual Cat. 419-300-900
US$25.34
54 Linch Pin - Ø7/16" x 1-3/4" [203-300-700] Linch Pin - Ø7/16" x 1-3/4" 203-300-700
US$2.23
56 Cap - Tube Insert Square [209-480-661] Cap - Tube Insert Square 209-480-661
US$21.88
57 Pin [406-346-410] Pin 406-346-410
US$6.17
58 PTO Complete Driveshaft - 540/1000rpm - Trimax Specification [406-340-840] PTO Complete Driveshaft - 540/1000rpm - Trimax Specification 406-340-840
US$461.24
60 Decal [424-100-350] Decal 424-100-350
Price on Request
63 Decal - Instruction - PTO Speed 540RPM [424-100-900] Decal - Instruction - PTO Speed 540RPM 424-100-900
US$6.06
64 Decal - Instruction - Wash Warning Large [424-101-100] Decal - Instruction - Wash Warning Large 424-101-100
US$3.69
66 Decal - Safety - Blade Warning / Thrown Objects [424-100-950] Decal - Safety - Blade Warning / Thrown Objects 424-100-950
US$4.10
36 Belt Guard Weldment - wDecal/AntiRatl Bungs [410-480-443] Belt Guard Weldment - wDecal/AntiRatl Bungs i See notes section for usage notes on this part 410-480-443
Price on Request
44 Gearbox - Counter Rotation - 540rpm [405-200-721] Gearbox - Counter Rotation - 540rpm i See notes section for usage notes on this part 405-200-721
US$1,099.41
